| Диаметър на въжето | Сумарна площ на телчетата | Ориентировъчна маса на 1000 [m] | Разрушаващо
усилие на
въжето [N] при
якост на
телчетата
N/мм2
(кгс/мм2) |
|||||||
| [mm] | [mm]2 | [kg] | 1370 (140) |
1470 (150) |
1570 (160) |
1670 (170) |
1770 (180) |
1860 (190) |
1960 (200) |
2060 (210) |
| 5,8 | 12,42 | 124,0 | 19600 | 20350 | ||||||
| 6,5 | 15,74 | 157,0 | 24900 | 25850 | ||||||
| 8,5 | 27,02 | 269,0 | 35950 | 42800 | 44400 | |||||
| 11,5 | 47,01 | 468,0 | 62600 | 66500 | 68750 | 71700 | 74550 | 77350 | ||
| 13,5 | 66,56 | 662,5 | 88650 | 94200 | 97100 | 100500 | 105500 | |||
| 15,5 | 85,54 | 851,5 | 113500 | 121000 | 124000 | 130000 | 136000 | |||
| 17,0 | 106,94 | 1065,0 | 142000 | 151000 | 155500 | 162500 | 170000 | |||
| 19,5 | 135,54 | 1350,0 | 157500 | 169000 | 180000 | 191500 | 197000 | 206500 | 215500 | |
| 21,5 | 167,64 | 1670,0 | 195000 | 208500 | 222500 | 237000 | 244500 | 255500 | 266500 | |
| 23,0 | 193,86 | 1930,0 | 225000 | 241500 | 258000 | 274000 | 283000 | 295000 | 307000 | |
| 25,0 | 225,39 | 2245,0 | 262500 | 281000 | 300000 | 318500 | 328500 | 343000 | 358500 | |
| 27,0 | 266,25 | 2650,0 | 310000 | 332000 | 354500 | 376500 | 388500 | 406000 | 423500 | |
| 29,0 | 303,00 | 3015,0 | 353000 | 378000 | 403500 | 428500 | 441500 | 462000 | 482000 | |
| 30,5 | 342,16 | 3405,0 | 398500 | 427000 | 455500 | 484000 | 499000 | 522000 | 544500 | |
| 33,0 | 392,07 | 3905,0 | 457000 | 489500 | 522000 | 555000 | 571500 | 597500 | 624000 | |
| 36,0 | 445,46 | 4435,0 | 5191000 | 556000 | 590000 | 630500 | 650000 | 679500 | 709000 | |
| 39,0 | 542,20 | 5395,0 | 632000 | 677000 | 722000 | 767000 | 791000 | 827500 | 863000 | |
| 43,0 | 670,56 | 6675,0 | 781500 | 836500 | 893000 | 949000 | 980000 | 1015000 | 1065000 | |
| 47,0 | 788,14 | 7845,0 | 918500 | 980000 | 1045000 | 1110000 | 1145000 | 1200000 | 1250000 | |
| 50,0 | 915,41 | 9110,0 | 1060000 | 1135000 | 1215000 | 1290000 | 1330000 | 1390000 | 1455000 | |
| 52,0 | 995,97 | 9910,0 | 1155000 | 1235000 | 1320000 | 1405000 | 1455000 | 1510000 | 1575000 | |
| 54,0 | 1064,98 | 10600,0 | 1235000 | 1325000 | 1415000 | 1500000 | 1550000 | 1620000 | 1695000 | |
| 56,0 | 1151,94 | 11450,0 | 1335000 | 1435000 | 1525000 | 1500000 | 1675000 | 1750000 | 1830000 | |
| 58,0 | 1211,97 | 12050,0 | 1410000 | 1505000 | 1610000 | 1715000 | 1765000 | 1845000 | 1925000 | |
| 62,0 | 1400,48 | 13950,0 | 1630000 | 1745000 | 1860000 | 1930000 | 2000000 | |||
| 66,5 | 1654,94 | 16450,0 | 1925000 | 2060000 | 2195000 | 2275000 | 2360000 | |||
| 71,0 | 1930,89 | 19200,0 | 2245000 | 2410000 | 2665000 | 2665000 | 2750000 | |||
| 75,0 | 2126,99 | 21150,0 | 2470000 | 2655000 | 2830000 | 2940000 | 3030000 | |||
