| Диаметър на въжето | Сумарна площ на телчетата | Ориентировъчна маса на 1000 [m] | Разрушаващо
усилие на
въжето [N] при
якост на
телчетата
N/мм2
(кгс/мм2) |
|||||||
| [mm] | [mm]2 | [kg] | 1370 (140) |
1470 (150) |
1570 (160) |
1670 (170) |
1770 (180) |
1860 (190) |
1960 (200) |
2060 (210) |
| 4.8 | 7,94 | 77.8 | 12050 | 12800 | 13350 | |||||
| 5.1 | 9,79 | 95.9 | 14900 | 15850 | 16500 | |||||
| 5,7 | 12,88 | 126,0 | 18800 | 19600 | 20900 | 21700 | ||||
| 6,4 | 15,63 | 153,0 | 22800 | 23800 | 25050 | 26300 | ||||
| 7,8 | 22.47 | 220,5 | 29900 | 31300 | 32750 | 34250 | 35750 | 37250 | ||
| 8,8 | 29.92 | 293,6 | 39800 | 42350 | 43650 | 45550 | 47600 | |||
| 10,5 | 39,54 | 387,5 | 52650 | 55950 | 57560 | 60300 | 62950 | |||
| 11,5 | 49,67 | 487,0 | 66150 | 70300 | 72450 | 75800 | 79050 | |||
| 12,0 | 54.07 | 530,0 | 72000 | 76500 | 78850 | 82350 | 86050 | |||
| 13,0 | 60.94 | 597,3 | 81100 | 86150 | 88700 | 92800 | 96800 | |||
| 14,0 | 73,38 | 719,0 | 97750 | 103500 | 106500 | 111000 | 116500 | |||
| 15,0 | 86,95 | 852,5 | 115500 | 122500 | 126500 | 132000 | 138000 | |||
| 16,5 | 101,68 | 996,5 | 118000 | 126500 | 135000 | 143500 | 147500 | 154500 | 161500 | |
| 17,5 | 117,58 | 1155,0 | 136500 | 146500 | 156000 | 166000 | 171500 | 178500 | 187000 | |
| 19,5 | 139,69 | 1370,0 | 162500 | 174000 | 183000 | 197000 | 203500 | 212500 | 221500 | |
| 20,5 | 158,19 | 1550,0 | 184000 | 137000 | 210500 | 223500 | 230500 | 241500 | 251500 | |
| 22,0 | 177,85 | 1745,0 | 207000 | 221500 | 236500 | 251000 | 259000 | 270500 | 283000 | |
| 23,0 | 198,67 | 1950,0 | 231000 | 247500 | 264500 | 281000 | 289500 | 302500 | 316000 | |
| 25,5 | 243,76 | 2390,0 | 284000 | 304000 | 324500 | 344500 | 335500 | 371500 | 388000 | |
| 28,0 | 293,48 | 2880,0 | 342000 | 366500 | 391000 | 415500 | 428000 | 447500 | 466500 | |
| 30,5 | 347,82 | 3410,0 | 405000 | 434000 | 463500 | 492000 | 507500 | 530500 | 553500 | |
| 32,5 | 406,76 | 3990,0 | 474000 | 508000 | 541500 | 575500 | 593000 | 620000 | 647000 | |
| 35,0 | 470,34 | 4610,0 | 548000 | 587500 | 626500 | 665500 | 686000 | 717500 | 748500 | |
| 37,0 | 513,49 | 5035,0 | 598500 | 641000 | 684000 | 726500 | 749000 | 783500 | 815000 | |
| 39,0 | 558,74 | 5475,0 | 651000 | 697500 | 744000 | 790500 | 815000 | 851500 | 886500 | |
| 40,0 | 595,18 | 5830,0 | 693500 | 743000 | 792500 | 841000 | 863000 | |||
| 41,0 | 632,78 | 6200,0 | 737500 | 790000 | 843000 | 872000 | 906500 | |||
| 43,5 | 71142 | 6975,0 | 829500 | 883500 | 948000 | 980000 | 1015000 | |||
| 45,0 | 752,48 | 7370,0 | 877000 | 939500 | 999500 | 1030000 | 1075000 | |||
| 46,0 | 794,70 | 7790,0 | 926500 | 989500 | 1055000 | 1090000 | 1135000 | |||
