| Диаметър на въжето | Сумарна площ на телчетата | Ориентировъчна маса на 1000 [m] | Разрушаващо
усилие на
въжето [N] при
якост на
телчетата
N/мм2 (кгс/мм2) |
|||||||
| [mm] | [mm]2 | [kg] | 1370 (140) |
1470 (150) |
1570 (160) |
1670 (170) |
1770 (180) |
1860 (190) |
1960 (200) |
2060 (210) |
| 3,6 | 4,98 | 48,8 | 7465 | 7880 | 8295 | 8600 | ||||
| 3,8 | 5,63 | 55,1 | 8400 | 8753 | 9350 | 9700 | ||||
| 4,1 | 6,55 | 64,1 | 9750 | 10150 | 10650 | 11250 | ||||
| 4,5 | 7,55 | 73,9 | 11250 | 11790 | 12500 | 15800 | ||||
| 4,8 | 8,62 | 84,4 | 12850 | 13400 | 13900 | 14450 | ||||
| 5,1 | 9,76 | 95,5 | 14600 | 15150 | 15800 | 16450 | ||||
| 5,6 | 11,90 | 116,5 | 15800 | 16800 | 17800 | 18550 | 19350 | 20000 | ||
| 6,2 | 14,47 | 141,6 | 19250 | 20100 | 21100 | 22250 | 23450 | 24350 | ||
| 6,9 | 18,05 | 176,6 | 24000 | 25500 | 26300 | 27450 | 28700 | 29850 | ||
| 7,6 | 21,57 | 211,0 | 28700 | 30500 | 32300 | 32900 | 34200 | 35500 | ||
| 8,3 | 26,15 | 256,0 | 34800 | 36950 | 38150 | 39850 | 41600 | 43200 | ||
| 9,1 | 31,18 | 305,0 | 41500 | 44100 | 45450 | 47500 | 49600 | 51700 | ||
| 9,9 | 36,66 | 358,6 | 48850 | 51850 | 53450 | 55950 | 58350 | |||
| 11,0 | 47,19 | 461,6 | 62860 | 66750 | 68800 | 72000 | 75100 | |||
| 12,0 | 53,87 | 527,0 | 71750 | 76200 | 78550 | 81900 | 85750 | |||
| 13,0 | 61,00 | 596,6 | 7105 | 76190 | 81250 | 86800 | 89000 | 92800 | 97000 | |
| 14,0 | 74,40 | 728,0 | 86700 | 92850 | 98950 | 105000 | 108000 | 112500 | 118000 | |
| 15,0 | 86,28 | 844,0 | 100000 | 127000 | 114500 | 122000 | 125500 | 131000 | 137000 | |
| 16,5 | 104,61 | 1025,0 | 121510 | 130000 | 139000 | 147500 | 152000 | 159000 | 166000 | |
| 18,0 | 124,73 | 1220,0 | 145000 | 155000 | 166000 | 176000 | 181500 | 189500 | 198000 | |
| 19,5 | 143,61 | 1405,0 | 167000 | 178500 | 191000 | 203000 | 209000 | 218500 | 228000 | |
| 21,0 | 167,03 | 1635,0 | 194000 | 208000 | 222000 | 236000 | 243500 | 254000 | 265500 | |
| 22,5 | 188,78 | 1850,1 | 220000 | 235530 | 251000 | 267000 | 275000 | 287500 | 303500 | |
| 24,0 | 215,49 | 2110,0 | 250000 | 269000 | 287000 | 304500 | 314000 | 328000 | 343000 | |
| 25,5 | 244,00 | 2390,0 | 284000 | 304500 | 324500 | 345000 | 356003 | 372000 | 388500 | |
| 27,0 | 274,31 | 2685,0 | 319000 | 342000 | 365000 | 388000 | 399500 | 418000 | 436500 | |
| 28,0 | 297,63 | 2910,0 | 346500 | 371000 | 396000 | 421000 | 434000 | 453500 | 473500 | |
| 30,5 | 356,72 | 3490,0 | 415500 | 445530 | 475000 | 504500 | 520000 | 544000 | 567500 | |
| 32,0 | 393,06 | 3845,0 | 458100 | 493500 | 523500 | 556000 | 573000 | 599500 | 625500 | |
| 33,5 | 431,18 | 4220,0 | 502500 | 538500 | 574000 | 610500 | 629000 | 658000 | 686000 | |
| 37,0 | 512,79 | 5015,0 | 597500 | 640000 | 683000 | 725000 | 748000 | 782500 | 816000 | |
| 39,5 | 586,59 | 5740,0 | 684000 | 732500 | 781500 | 828000 | 856000 | 791500 | 938500 | |
| 42,0 | 668,12 | 6535,0 | 779000 | 833000 | 890000 | 945000 | 975000 | 1010000 | 1060000 | |
| 44,5 | 755,11 | 7385,0 | 880500 | 941000 | 1000000 | 1035000 | 1075000 | |||
| 47,5 | 861,98 | 8430,0 | 1000000 | 1070000 | 1145000 | 1185000 | 1230000 | |||
| 51,0 | 976,03 | 9545,0 | 1135000 | 1215000 | 1295000 | 1340000 | 1395000 | |||
| 56,0 | 1190,53 | 116550,0 | 1385000 | 1490000 | 1580000 | 1635000 | 1705000 | |||
